*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.* Make: MIGHTY VIPER Model: DM100 Year: 2002 Condition: Used – Good Equipped With: Mitsubishi 600M CNC Control 64″ X 80″ Table for Die Mold Applications 30 Station Side Mount Tool Changer 50 Taper Geared Head 6000 RPM Spindle Powerful 35 HP high torque spindle motor PCMCIA Card Slot RS-252 Port Spindle Orientation Box Way Construction Portable manual pulse generator Flood coolant with large separate coolant tank Base Flush Chip Disposal with Dual Auger Chip Conveyor Chiller Unit Books and Manuals Replacement Cost over $300000.00 Travels: X-Axis: 61.75″ Y-Axis: 86.66″ Z-Axis: 36.22″ Distance Between Columns: 102.36″ Spindle Nose to Table (Min.- Max.): 7.4″- 43.7″ Table: Length: 64.96″ Width: 80.31″ T-Slot: 0.87″ Wide X 20 X 7.87″ Max Weight on Table: 22000 lbs Feed rates: Rapid X Y & Z: 590 inch per minute Cutting Feedrate: .04″ – 376″ inch per minute Spindle: Taper Size: 50 Speed Range: 6000 RPM Spindle Power: 35 HP Tool Changer: Capacity: 30 Max Tool Weight: 43 lbs Max Tool Length: 13.77″ Max Tool Dia.: 5.2 – 7.7″ General: Air Required: 100 psi 4 scfm Power: 220v / 3-Phase 65 Kva Floor Dimensions: 224″ X 144″ x 130″ High with Hydraulic Unit Chip Conveyor Chiller unit Weight: 55000 lbs. “No Charges for loading at list Price”
