Description Signet 2260/2270 Ultrasonic Level Temperature Sensor The type 2260/2270 is a rugged, high performance ultrasonic level measurement transmitter, having transducer and processing electronics and a display/programming unit incorporated in one single housing.All type 2260 Level Transmitters are using established high end pulse echo transducers, which provide narrow beam angles and reliable measurement ranges up to a distance of 15 meters.For small, stand alone tanks the transmitter provides a simple 2-wire 4 to 20 mA output, with additional power relay contacts. It can be programmed using push buttons and the large, graphic display. For large and/or multiple tank applications versions with HART interface are recommended, communicating directly with a panel mount controller or PLC. The HART protocol can easily be used for programming these versions. PVDF Ultrasonic Level Sensor CODE REF Display & 4-20mA output 3-2260-V-0DB-6 159300103 Blind 4-20mA output 3-2270-V-1B-6 159300163 Temperature/Pressure: Wetted Materials: PDVF Additional features: Platinum RTD in extended tip for quick response In-line Mounting styles: 3/4 inch NPT Submersible mounting: 3/4 inch NPT Operating Temperature:** In-line: -10° to 100°C (14 to 212°F) Submersible: -10° to 85°C (14° to 185°F) Operating Pressures:** 0 to 16 bar (0 to 232 psi) Compatibility: 8350, 8900 or 9900 **check operating temperature/pressure graphs in catalog for derating information
