Flow rate of hand shower at 3 bar: 7,8 l/min Maximum flow rate for Showerpipe at 3 bar: 8 l/min Minimum flow pressure: 0,5 bar Max. operating pressure: 10 bar Ball-joint: overhead shower angle adjustable Convenient spray selection via Select button on the hand shower Variable wall support Variable drilling hole distance: 750 – 850 mm Pipe can be shortened in height Shower bar diameter: 22 mm height-adjustable hand shower holder Shower arm length overhead Shower: 350 mm Suitable for continuous flow water heaters with an output of 18 kW Mounting type: exposed installation Connection dimension: DN15 Connection thread: G ½ Centre distance: 150 12 mm Ceramic cartridge Temperature limitation adjustable EU taxonomy: max. 8 l/min – Do No Significant Harm (DNSH) Removable shower head Slider rotatable on the pipe for left or right operation Flow rate Rain spray at 3 bar: 7,8 l/min
