Matsuura MAM72-100H 5 Axis CNC Horizontal Machining Center - Mill
$53.72
$67.15
*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.* Make: Matsuura Model: MAM72-100H Year: 2014 Condition: Used – Good Features: Fanuc G-Tech 30i Series CNC Control Twin Pallets Full 4th Axis 24.8” x 24.8” NC Programmable Swiveling Trunnion Table 5 Axis Simultaneous Machining 12,000 RPM High Speed Spindle BT-50 Spindle Taper Rigid Tapping Coolant System Through Spindle Coolant 150 Station Automatic Tool Changer Spindle Chiller Uni Chip Blaster Chip Conveyor Travels: X Axis: 41.43″″ Y Axis: 36.22″ Z Axis: 25.98″ A Axis: 150° (–120° – 30°) ( Table Tilt ) C Axis: 360° ( Table Rotate ) Rapid Traverse Rates X, Y Axis: 2362 Inch Per Minute Rapid Traverse Rates Z Axis: 1968 Inch Per Minute Pallet: Number of Pallets: 2 Station Pallet Surface: 24.80″ x 24.80″ Max Workpiece Diameter: 39.37″ Max Workpiece Height: 30.31″ Max Weight on Table: 1719 lbs Spindle: Taper Size: BT-50 Speed Range: 45 – 12,000 RPM Spindle Power: 30 HP Automatic Tool Changer: Capacity: 150 Tools Taper: BT-50 Max Tool Diameter: 4.33″ Max Tool Length: 23.62″ Max Tool Weight: 44 lbs. General: Air Required: 100 psi 4 scfm Power: 220v / 66FLA / 3-Phase / 122 kva Overall Dimensions: 277″ X 152″ X 139″ High Approx. Weight: lbs Approx.
