Mazak Integrex 300II-SY Multi Axis CNC Turning Center -Lathe

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.* Make: Mazak Model: Integrex 300II-SY Year: 2002 Condition: Used – Good Equipped With: Mazatrol Fusion 640MT CNC Control 10,000 RPM Pendulum Milling Head 40 Station Tool Magazine Sub Spindle Full C-Axis on Both Spindles Y Axis Capability 12.4″ 3-Jaw Chuck on Main Spindle 10.4″ 3-Jaw Chuck on Sub Spindle Tool Presetter Part Cather Rigid Tapping Coolant System Chip Conveyor Transformer Foot Switches Books and Manuals Capacity: Max Turning Diameter: 30″ Max Turning Length: 60″ Max Bar Capacity: 3.46″ Swing Over Bed: 30.0″ Distance Between Centers: 60″ Travels: X Axis Travel: 24.80″ Y Axis Travel: 9.06″ ( /-4.53″) Z Axis Travel: 62.40″ W Axis Travel (Sub Spindle): 60.24″ B Axis Travel: 225 Degree C Axis: 360 Degree (0.001 Degree) X Rapid Traverse Rate: 1181 Inch Per Minute Y Rapid Traverse Rate: 591 Inch Per Minute Z Rapid Traverse Rate: 1181 Inch Per Minute Main Spindle: Main Spindle Nose: A2-8 Main Spindle Bore: 4.1″ Main Spindle Speed: 35 – 3500 RPM Main Spindle Motor: 40 HP Sub Spindle: Sub Spindle Nose: A2-8 Sub Spindle Bore: 3.1″ Sub Spindle Speed: 35 – 3500 RPM Sub Spindle Motor: 30 HP Milling Head: Single Station Pendulum Head with 40 ATC Tool Type: Capto C6 Spindle Speed: 15-10,000 RPM Spindle Motor: 25 HP Spindle 90° Index Time: 0.5 sec General: Power Source: AC 200 V, Three Phase, 50/60 Hz Power Requirement: 62.8 Kva Overall Dimensions: 193.4″ x 93.0″ x 110.2″ High Approx. Weight: 22,000 lbs Approx.
