Kitako MT4-200M Multi Spindle CNC Turn Mill Center -C Axis Lathe

*All specifications are approximations and are subject to verification. Comes as shown in the images. Please give us a call if you have any questions before purchasing. All sales are final.* SKU: 112080 Make: Kitako Model: MT4200M Year: 1999 Condition: Used – Good Features: Fanuc 18i-T Series 6 Axis CNC Control (4 no.) Spindles Design (2 no.) In Machining Area (2 no.) in Loading Area (4 no.) Collet Chucks (Capable 8″ Chucks) Servo Controlled Full C-Axis on Spindles Twin Turrets with Live Tools 8 Station Left Turret with Live Tools 8 Station Right Turret with Live Tools High Pressure Coolant System Foot Switches Coolant Tank Automatic Lubrication Capacity: Max Turning Diameter Left Turret : 7.9″ Max Turning Diameter Right Turret : 7.9″ Max Swing : 8.3″ Max Turning Length: 6.3″ Max Bar Capacity Main Spindle : 1.56″ Travels: X1 Axis Travel (Left Turret): 6.69″ X2 Axis Travel (Right Turret) : 6.69″ Z1 Axis Travel (Left Turret) : 9.84″ Z2 Axis Travel (Right Turret) : 9.84″ C Axis: 360° (0.001°) Feedrate: X1, X2 Axis: 945 IPM Rapid Traverse Z1, Z2 Axis: 787 IPM Rapid Traverse Spindle: No. of Spindles: 4 Spindle Bore: 1.97″ Spindle Nose: A2-6 Spindle Speed: 50-4000 RPM Spindle Power: 20 HP Turret: Left Turret Capacity: 8 Stations Right Turret Capacity: 8 Stations Live Milling Speed: RPM? Live Milling Motor: HP? Turret Index Time (Tool to Tool): sec? Turret Tool Type: BMT General: Power Source: AC 220v / 3-Phase / 60 Hz Power Requirement: kva ? Machine Dimensions: 106″ x 78″ x 85″ Height Machine Weight: 17,500 lbs. Approx.
